Hose Reel - 36m x 19mm

SKU: HREELV36

POA

Share:
  • Dispatch in: 1-2 days


Calculate Shipping

Workshop360 Hose Reel 19mm x 36m


Ease of use and heavy duty parts make this Fire Hose Reel suited to almost any application. Our fixed Fire Hose Reel comes with all parts required: 25mm Ball Valve (including nozzle locking device), Hose Guide and Wall Bracket.

  • *1 year warranty from date of delivery (warranty covers cost of hose reel only)
  • Easy to operate and maintain
  • Meets or exceeds requirements of Australian Standard AS1221


    Technical Details

  • Approvals : AS/NZS 1221:1997
  • Back Plate to Wall : 50mm
  • Ball Valve Assembly Construction : Brass
  • Ball Valve Assembly Finish : Zinc Coated
  • Box Quantity : 1
  • Dimensions : W540 x D220 x H540mm
  • Front and Back Plate Construction : Steel
  • Front and Back Plate Finish : Signal Red
  • Gasket Construction : Rubber
  • Gross Mass : 22kg (approx)
  • Guide Arm Construction : Swivel
  • Guide Arm Finish : Zinc Plated
  • Inlet Pipe / Union Construction : Galvanised
  • Maximum Working Pressure : 1350kPa
  • Minimum Inlet Pressure : 220kPa
  • Model Number : FSHRV36
  • Mounting Plate Construction : Steel
  • Mounting Plate Finish : Signal Red
  • Nozzle Construction : Twist Action Brass
  • Pallet Quantity : 20
  • Pipe Construction : Galvanised
  • Single Units : Yes
  • STD Hose Length & Diameter : 36m x 19mm diameter
  • Support Assembly Construction : Mild Steel
  • Support Assembly Finish : Zinc Plated
  • Valve Stem : Galvanised
  • Warranty : 1 year*

(HREELV36)

SKU HREELV36
Brand FlameStop
Shipping Weight 22.0000kg
Shipping Width 0.540m
Shipping Height 0.540m
Shipping Length 0.220m
