Tyre Inflation Cage - 1510 x 610 x 1570mm

Current lead time is 2-3 weeks

SKU: STBC15

POA

Share:
  • Dispatch in: 7-10 days


Calculate Shipping

The STBC15 Tyre Inflation Cage is designed for the safe inflation of tyres.  Working with tyres, particularly truck and machinery tyres, is dangerous because of their compressed air or gas, size and weight. The uncontrolled release of stored energy can have serious, even fatal consequences. When a tyre bursts or assemblies release, they can be propelled long distance at great speed with flying shrapnell. This heavy duty cage is constructed to provide protection against the risk of injury to workers and damage to plant and structures caused by a tyre blast.

FEATURES:

  • Provides protection for personnel when inflating tyres
  • Prevents risk of injury and damage caused by tyre blast
  • Suits tyres sizes up to 1400mm diameter by 500mm wide
  • Heavy duty construction designed to withstand impact and force
  • Locating guides on base hold wheel in position
  • Mesh sides help enclose any flying particles
  • Fork pockets and crane lugs fitted for easy location in the workshop
  • Finite Element Analysis confirms design is engineered to withstand the most severe blast
  • Designed and certified to relevant Australian standards
  • Enamel paint finish

Supplied as a fully assembled unit

SPECIFICATIONS:

 Maximum Tyre Size  1400(dia) x 500(w) mm
 Internal  Dimensions  1450(l) x 500(w) x 1460(h) mm
 Overall Dimensions  1510(l) x 610(w) x 1570(h) mm
 Unit Weight   200kg
 Fork Pocket Size  160 x 60mm
 Fork Pocket Centres  800mm

---

Please note: this item may incur additional shipping fee’s when shipped to a residential address. Please refer to our shipping policy for more information.



(STBC15)

SKU STBC15
Brand East West Engineering
Shipping Weight 480.0000kg
Shipping Width 0.600m
Shipping Height 1.580m
Shipping Length 4.500m
