SeekTech Line Transmitter w/ Bluetooth

SKU: 49343R

POA

Share:
  • Dispatch in: 5-7 days

Minimum Order Quantity 1

Calculate Shipping

ST-33Q+ Line Transmitter with Bluetooth®

The RIDGID® ST-33Q+ Line Transmitter with Bluetooth is the ideal transmitter for inducing current onto a target line. It will also direct connect using any frequency from 10Hz to 490kHz* with power up to 10 Watts. The ST-33Q+ also allows the flexibility of using D-Cell alkaline batteries or 18V rechargeable RIDGID batteries for minimal interruptions on the job. The new Bluetooth feature on the ST-33Q+ allows you to finish complex locates faster by wirelessly changing the transmitted frequency from the SR-24 receiver from up to 200 yards away.

Features

  • Distance - Induce over 8 times more current than traditional transmitters. More current means you can walk and trace further than ever before.
  • Versatility - Power options include Lithium-Ion 18 V rechargeable battery, six D-cell batteries, or an external 10-28 VDC power source.
  • Accuracy - Induce more current at lower frequencies. Lower frequencies are less prone to jump onto other lines in congested areas reducing distortion and increasing accuracy.
  • Speed - Use with a SR-24 Bluetooth-enabled locator, to control the ST-33Q+ settings wirelessly from the SR-24 receiver. Change transmitted frequency remotely from up to 200 yards away.

Specifications

  • ST-33Q+ Line Transmitter with Bluetooth
  • Frequencies
    • Direct Connect (pre-programmed): 128 Hz, 1 kHz, 8 kHz, 33 kHz, 93 kHz, 262 kHz.*
    • Direct Connect (user programmed): Any Frequency from 10 Hz – 490 kHz*
    • Induction: 8 kHz or 33 kHz.
    • * Up to 93 kHz for devices sold in Europe and Australia and New Zealand.
  • Other Specifications
    • Max Power: 10 watts.
    • Bluetooth Max Wireless Range: 200 yards (183 m).
    • (Batteries sold separately)
  • Weight: 11.1lb (5kg)

(49343R)

SKU 49343R
Barcode # 95691493439
Brand Ridgid
Shipping Weight 6.6000kg
Shipping Width 0.530m
Shipping Height 0.520m
Shipping Length 0.300m
