TradeQuip Air/Hydraulic Bottle Jack Squat - 20,000kg

SKU: 2051T

POA

Share:
  • Dispatch in: 3-4 days


Calculate Shipping

This TradeQuip "Made for the Trade" Air/ Hydraulic "Low Profile" Bottle Jack is designed to operate pneumatically. This unit provides enough lifting power for use with farm vehicles, heavy duty machinery, industrial construction equipment and more.  It’s low profile design get’s you out of tight situations with ease.

Powerful, Heavy-Duty Operation

This 20,000kg heavy-duty air/hydraulic bottle jack is the perfect choice for a wide variety of uses. The power of air makes it easy to lift farm vehicles, trucks, lawn mowers, heavy equipment and other large loads!

Versatility To Get The Job Done

Use this workhorse with a 100-145 PSI rated air pressure supply to lighten the load and provide the fast, strong lifting power you need. The 150–260mm lift range raises the load to the desired height and a knurled, heat-treated pad with screw height adjustment allows you to fine-tune the jack from there.

Added Safety Overload Protection

Carelessness can cause injuries, but this jack gives you extra peace of mind. It's fitted with a safety overload valve for extra protection. Even if you load the jack up with too much weight, the safety overload kicks in and gently lowers the unit before the operator is put in a dangerous situation.

Use It Day In And Day Out

This Bottle Jack is designed for durability. A rugged high-grade steel frame is teamed with a lead-free paint finish that covers the entire surface to ensure long-lasting wear and help prevent rust. The paint is oil-, grease- and dirt-resistant for easy cleanup no matter how often you put this jack to work.

Features:

  • All air bottle jacks have chrome plated rams
  • Built-in by-pass device protects hydraulic system from over pumping damage
  • Versatile "quick connector" design provides for easy removal of air hose from air motor allowing compact storage or remote operation
  • Compact yet powerful Air Turbo Motor

Specifications:

  • Safe Working Capacity: 20,000kg
  • Minimum Height: 148mm
  • Maximum Height: 259mm
  • Hydraulic Stroke: 66mm
  • Screw Extension Height: 45mm
  • Operating Air Pressure: 100-145psi
  • Base Area: 201x135mm
  • Carton: 355x165x165mm
  • Gross Weight: 10kg

Intended Use

For heavy-duty truck, agriculture, construction, mining, automotive, and trailer applications whenever clearance is limited or very low to the ground.

IMPORTANT:   NEVER get beneath a vehicle that is only supported by a jack. ALWAYS chock the vehicle wheels and use Jack Support Stands.
