Girder Geared Trolley (Violet) - 1t x 203mm

Beaver geared girder trolleys are fully adjustable to suit varying flange widths up to a maximum of 350mm with the simple addition or subtraction of spacers or nuts on a suspension pin. This trolley complies to AS 1418.2 and approved Colour Coded to Match International Lifting Standard.

These girder trolleys are manufactured to have a lightweight but robust all-steel construction. The hand chain has a special corrosion resistance zinc dichromate (gold) finish. Anti-tilt blocks fitted as standard for additional safety. Beaver geared trolleys are not designed for passenger elevator applications and must not be used for this purpose. Selection and calculation of the proper beam construction are the responsiblity of the user.

Each Beaver girder trolley has an individual serial number stamped on the stainless steel identification plate. This number coincides directly to the test certificate of the product (which is provided), for quick and easy tracing and reference. These products are also operationally tested to 150% of its rated capacity.

Features:

• Beaver Push and Geared Girder Trolleys are colour coded for even safer lifting capacity recognition.
• These Push and Geared Trolleys are designed to run on either RSJ or Universal Beams.
• All Beaver Push and Geared Trolleys are fully adjustable to suit varying flange widths up to a maximum of 350mm with the simple addition or subtraction of spacers or nuts on a suspension pin.
• Easy and simple mounting in different locations.
• Independent hanging eye for easy attachment of chain blocks.
• Precision ball bearing trolley wheels complete with dust cover and clip.
• Lightweight robust all-steel construction.
• Anti-derailment end plates fitted as standard for added safety.
• Anti-tilt blocks fitted as standard for additional safety.
• Hand chain on Geared Trolleys has a special, corrosion resistant Zinc dichromate (gold) finish.
• Each Beaver Girder Trolley has an individual serial number stamped on the stainless steel identification plate. This number coincides directly to the test certificate of the product, for quick and easy tracing and reference.
• Every Beaver Girder Trolley is operationally tested to 150% of its rated capacity and comes with a test certificate.
• Spare trolley wheels are available, complete with full repair facilities and re-testing in Beaver’s NATA Accredited test facility.

Technical Specifications:
